lviCycle D1000

lviCycle D1000

Category:

Description

Product description

Dedicated battery test system

The IviCycle D1000 is designed to be your perfect partner for high channel-count battery applications. The IviCycle offers a low cost-per-channel, high volume testing solution and extensive data storage capability.

Complete solution

The IviCycle is a multi-channel DC battery test system. The channels are divided over 4 modules. It is possible to mix and match different IviCycle modules to create a custom-built instrument with the desired number of channels of varying compliance, and with DC only or EIS capability.

The D1000 modules each have 8 channels of ?1A/-0.2 to +5V compliance. The modules are available as DC versions only (no EIS). This means that simultaneous/parallel DC measurements are possible on all channels. The IviCycle has an integrated DataSecure module that stores all data for each channel completely independently from the computer. This ensures that if there is a communication loss or a computer crash/update, the measurement will continue and data will not be lost. This provides peace-of-mind for long duration, high throughput testing. The IviCycle unit is built into a 19inch rack mountable housing for easy incorporation into existing storage racks, or as a stand-alone bench-top multi-channel system.

Safety

The maximum current or potential of the instrument can be defined by the operator. Thus valuable samples may be protected, and unsafe situations prevented.

Data security & Connection

The IviCycle is equipped with an integrated DataSecure module:

  • Data is stored on board independent of the computer.
  • Connection of multiple PCs is possible

Software

The IviCycle is controlled via Ivium?s own software, IviumSoft. This versatile, yet intuitive software, allows instrument control, data management and analysis, etc. The IviCycle can also be controlled from LabVIEWTM, C++, Delphi, etc. A full suite of software is included as standard with each instrument.

  • Control of separate channels individually
  • All channels simultaneously
  • Synchronous start
  • Data from different channels plotted individually or in 1 single graph




Specifications

System performance
Current compliance
?1A
Maximum applied voltage
-0.2V to +5V
Electrode connections
4; WE, CE, RE, S with 4mm banana plugs
Potentiostat bandwidth
>1kHz
Signal acquisition
Dual channel 24bit ADC, 1,000 samples/s
Channel combination
No
Potentiostat
Applied potential range
-0.2 to +5V, 0.15mV res.
Applied potential accuracy
0.2% of value or 1mV
Current ranges
?10?A to ?1A
Measured current resolution
0.00005% of current range, minimum 5pA
Measured current accuracy
0.025% of FSR
Galvanostat
Applied current resolution
0.015% of applied current range
Applied current accuracy
0.2%
Galvanostatic current ranges
?10?A to ?1A
Potential ranges
?5V
Measured potential resolution
0.6?V
Measured potential accuracy
0.2% of value or 1mV
Electrometer
Input impedance
>1000Gohm //<20pF
Input bias current
<20pA
Bandwidth
>150kHz
Peripheral connections
Analog in/out
?10V input only, 1000GOhm, 24bit resolution
Data Acquisition
Stored no. of datapoints
20M each channel
Environment
Power requirements
100-240V, 50-60Hz, 500VA
Interfacing
USB/LAN (Ethernet)
Size (w x d x h)
44 x 26 x 22cm
Weight
12.5kg
PC requirements
Windows 8/10/11, with free USB port
Integrated DataSecure
Stored no. of data points: 20M each channel

Specifications subject to change, Ivium Technologies ?2025
